TM2AMI4LT 1PCS New Schneider I/O expansion module, Modicon M238 logic controller-image

TM2AMI4LT 1PCS New Schneider I/O expansion module, Modicon M238 logic controller

$ 701.72

Country of Origin: Germany MPN: TM2AMI4LT Brand: Schneider Electric UPC: Does not apply gtin13: Does not apply

Description

Range of Product Modicon M238 logic controller Product or Component Type I/O expansion module Analogue input number 4 Analogue input type voltage 0...10 V non differential Pt 100/Pt 1000 temperature probe - 200...600 °C non differential Ni 100/Ni 1000 temperature probe - 50...150 °C non differential current 0...20 mA non differential Cross talk <= 1 LSB Complementary Range Compatibility Twido Advantys OTB Analogue input resolution 12 bits LSB value 2.5 mV voltage voltage 4.8 µA current current 0.2 °C temperature probe Pt 100/Pt 1000 0.05 °C temperature probe Ni 100/Ni 1000 Permissible continuous overload 40 mA current 13 V voltage Input impedance >= 10 kOhm temperature probe 470 Ohm current 10 kOhm voltage Sampling duration 160 ms Acquisition period 320 ms per channel + 1 controller cycle time temperature probe 160 ms per channel + 1 controller cycle time voltage/current Measurement error +/- 0.2 % of full scale 0...10 V 0...10 V 25 °C +/- 0.2 % of full scale 4...20 mA 4...20 mA 25 °C +/- 0.4 % of full scale Pt 100/Pt 1000, Ni 100/ Ni 1000 25 °C Temperature coefficient +/- 0.004 %FS/°C temperature probe +/- 0.009 %FS/°C current +/- 0.009 %FS/°C voltage Repeat accuracy +/-0.1 %FS Non-linearity +/- 0.02 %FS Total error +/-0.5 %FS Type of Cable Shielded cable Insulation between channel and internal logic Photocoupler Supply External supply [Us] rated supply voltage 24 V DC Supply voltage limits 20.4…28.8 V Electrical connection 1 removable screw terminal block Current consumption 50 mA 5 V DC internal 60 mA 24 V DC external Net Weight 0.187 lb(US) (0.085 kg)
