ESD5500E Speed Controller with ADC225-12V Actuator and MSP675 Magnetic Sensor-image

ESD5500E Speed Controller with ADC225-12V Actuator and MSP675 Magnetic Sensor

$ 147.31

Nominal Rated Input Voltage: 12 V Brand: Unbranded Model: ESD5500E+ADC225-12V+MSP675 UPC: Does not apply Compatible Brand: Universal Produktart: Generator gtin13: Does not apply Type: generator Manufacturer Part Number: Does Not Apply MPN: Does Not Apply

Description

ESD5500E Speed Controller ADC225-12V Actuator + MSP675 Magnetic Speed Sensor New Specifications: PERFORMANCE: Available Torque Max1.0Lb-ft(1.4Nm) Maximum Operating Shaft Angular Travel 25+1degree CW/CCW POWER INPUT: Operating voltage 12VDC Normal Operating Current 2A at 12VDC 1A at 24VDC Maximum CurrentContinuously Rated 6A at 12VDC 3A at 24VDC ENVIROMENTAL: Temperature Range -54 to 95 Relative Humidity up to 100% All Surface finishes Fungus proof and corrosion resistant PHISICAL: Weight 2.3 kg Mounting Any position, electrical connector at the top preferred RELIABILITY: Vibration up to 20G @50-500 Hz Testing 100% Tested MATING HARDWARE Connector Supplied With Actuator Lever LE1500-2 Rod End Bearings(to attach a 12#20 HD linkage rod to lever) BR100(Right Hand)&BR101(Left Hand)----(Don't include!) Wiring Harness HD225 4ft. harness supplied with actuator, other length available from Actuator--------------(Don't include!) T echnical Specifications : Isochronous Operation/Steady State Stability ± 0.25% or better Speed Range/Governor 1K-7K5 Hz Speed Drift with Temperature ± 1% Maximun IDLE Adjustment 160 ± 20Hz ~ 60% of set speed Droop adjustment Min.(K-L Jumpered) 15Hz. ± 6Hz. per 1.0 A change Droop adjustment Max.(K-L Jumpered) 400Hz. ± 75Hz. per 1.0 A change Droop Adj. Max. (K-L Jumpered) 875Hz., ± 75Hz. per 1.0 A change Droop Adj. Min. (K-L Jumpered) 15Hz., ± 6Hz. per 1.0 A change Notice: Because,the international air shipping forbid to ship liquid,powder and batteries, If you purchased goods containing such items, we will not be putting them packing. Thank you for your support. Shipping ： Please read this before buying International Shipping may Be Delayed Due to Customs. Customers are Responsible For All Import Charges, Tariffs, Duties, Taxes, and Fees Associated with Import of the product. Shipping Charges does not include any Import Charges, Tariffs, Duties, Taxes, and Fees Associated with it. We are not responsible for undeliverable address.We reserve the right to charge the shipping fee again for returned items due to wrong address. Contact us ： Please contact us with any comments, questions or suggestions that you may have bysending ebay message, All the mail will be replied within 24 hours.
